C type
center back
put-in
square
1000pcs
Jiangsu, China
HF or customer logo
PCG Series
2.5", 3",3.5",63MM,70MM,80MM
black steel
brass
2.5%,1.6%
bottom or back
1/4'',1/2'', 1/8",3/8"BSP,NPT, PT (ZG,
0-120℃
Plastic
Applications
·Heating systems
·Combi-boilers with hot water and heating
Special Features
·Combined indication for pressure and temperature
·Customized scale ranges
Description
·Due to the combination of a pressure gauge and a bimetal thermometer the instrument can be used flexibly in a wide variety of applications.
·Back or bottom mount process connection.
Applications
·Heating systems
·Combi-boilers with hot water and heating
Special Features
·Combined indication for pressure and temperature
·Customized scale ranges
Description
·Due to the combination of a pressure gauge and a bimetal thermometer the instrument can be used flexibly in a wide variety of applications.
·Back or bottom mount process connection.
| Dial | 2.5” (63mm), 3” (75mm) aluminum, painted white blue red |
| Case | Steel, painted black |
| Lens | 2.5″ (63mm): Acrylic, threaded 3” (75mm): Glass |
| Ring | 3” (75mm): Chrome |
| Stem | Brass |
| Socket | Brass |
| Movement | Brass and phosphor bronze |
| Sensing Element | Temperature: Bi-metallic coil Pressure: Bourdon tube |
| Pointer | Aluminum, anodized black |
| Welding | Tin-alloy solder |
| Pressure Limit | 75% of full scale range |
| Ambient Temperature | 23°F to 122°F (-5°C to 50°C) |
| Process Temperature | 75% of full scale range |
| Accuracy | Pressure: ±3-2-3% Temperature: ±3% of full scale |
| Dial | 2.5” (63mm), 3” (75mm) aluminum, painted white blue red |
| Case | Steel, painted black |
| Lens | 2.5″ (63mm): Acrylic, threaded 3” (75mm): Glass |
| Ring | 3” (75mm): Chrome |
| Stem | Brass |
| Socket | Brass |
| Movement | Brass and phosphor bronze |
| Sensing Element | Temperature: Bi-metallic coil Pressure: Bourdon tube |
| Pointer | Aluminum, anodized black |
| Welding | Tin-alloy solder |
| Pressure Limit | 75% of full scale range |
| Ambient Temperature | 23°F to 122°F (-5°C to 50°C) |
| Process Temperature | 75% of full scale range |
| Accuracy | Pressure: ±3-2-3% Temperature: ±3% of full scale |
